In brief

A through-floor lift is a small cabin on its own rails that carries one person, standing or seated, between two floors through an opening cut in the ceiling, while a platform lift usually solves a shorter rise such as a raised front door and an enclosed home lift runs in its own shaft. Start with the journey, the wheelchair or walker and the stops you need; the survey of your home decides the actual proposal.

IN THIS GUIDE

Connect the category to the route

A through-floor lift is a small cabin that travels on its own rails between two floors, passing through an opening cut in the ceiling of the room below. Savaria describes its Luma as a winding drum with a hidden rope system on self-supporting rails, with no shaft, no pit and no support wall, two stops and a footprint of 38 by 47 inches. A platform lift is different. Savaria describes its Multilift for changes such as reaching a raised front door from the ground and states that its vertical platform lifts do not go through a floor.

Draw the journey before you look at finishes. Is the problem a raised entrance, getting between two rooms on different floors, or reaching several levels? Note whether the person will travel seated in their own wheelchair, move across into a lift seat, or stand with a walker. Write down the actual chair or walker and its measurements.

Compare the building scope explicitly

  • Ask each provider to name its lift, the landings, the entrance arrangement and the preparation work. Put the floor opening, any enclosure or shaft, structural support, electrical supply and finishing on separate lines. Ask: "Which of these lines are in your price, and which will another trade have to do?"

  • Write down which professional checks the structure and which local authority or inspector has to be consulted. Rules differ from place to place, so leave that line blank until someone local confirms it. A lift that looks simpler may still need serious preparation. A brochure footprint is a starting point for a survey, not permission to cut through a floor.

Worked decision: porch access versus bedroom access

Suppose your mother uses a wheelchair and her front door sits several steps above the garden path. Your neighbour's father also uses a wheelchair, but his problem is getting from the living room to the bedroom upstairs. Same chair, different journeys. A platform lift quoted for the front entrance does not solve the bedroom trip just because it carries the same wheelchair.

Give providers each journey as its own brief. Ask what each system can serve and what work would still remain. If the entrance is the urgent problem, judge that project on its own. There is no need to buy a large indoor lift to solve a smaller entrance job before an entrance lift or ramp has been compared fairly.

Illustrative two-level home interior with a living area and upper landing.
Editorial illustration

Complete a system comparison before prices

For each proposal, fill in the table below with the provider's drawing or written answer for that model. Write “not applicable” only once the provider has confirmed that a task does not belong to its system. Keep unconfirmed items visible; they can change the project far more than a handsome cabin finish.

Filling it in may lead you to book a site visit for only one type of lift. It may also show that moving a bedroom downstairs, or another assessed access route, solves the urgent need for now. Suitability and building approval still come from the survey and the right professionals.

  • JourneyEntry, destination, height change and number of stops.
  • PassengerMobility aid, transfer requirement and configuration limits.
  • WorksFloor opening, support, enclosure, power and finishing.
  • ApprovalNamed professional and local confirmation still required.

Classify the route before classifying the lift

Begin with one sentence naming where the journey starts and ends. Driveway to raised front door, downstairs living room to upstairs bedroom, and basement to two upper floors are three different requests. Write the actual changes in level and the stops you need, before choosing a machine. A search for wheelchair lift can return the same broad label for equipment built for very different routes.

  • Describe what travels with the person and how it is normally used. A compact walker, a wheelchair and a scooter are not interchangeable just because the product category mentions mobility. Savaria, for instance, says its standard Luma takes compact aids such as rollators, walkers and canes, and points wheelchair users to its larger Luma L, Telecab or Telecab 17 models. Ask the provider for the exact inside measurements, permitted uses and entry layout. An occupational therapist can assess transfers.

  • Keep indoor room-to-room travel separate from entrance access. An entrance project may involve an outside path, porch, gate or garage. An indoor project usually involves a floor opening and changes to how rooms are arranged. Some households need both, but one installation will not automatically solve both. Give each journey its own label in the brief so providers can say clearly which one their offer covers and which remains outside it.

Count the destinations you really need. Do not describe three levels as two floors just because the first conversation is about the bedroom. Equally, avoid asking for extra stops only to make a premium lift sound future-proof when there is no clear use for them. Ask how the offered model fits the route you need today, and treat any later extension as a separate question, not a promise built into this purchase.

Finally, decide what matters most right now. Your father may mainly want safe, reliable access to the front door, while the family is also thinking about a bedroom lift later. Compare each task on its own scope. A smaller entrance solution can be considered without pretending it replaces indoor access that is needed. A clear description of the route stops a broad category name from becoming a reason to buy more equipment than the present need calls for.

Illustrative raised home entrance above a garden path with stone steps.
Editorial illustration

Use manufacturer examples to ask precise category questions

Platform lift and through-floor lift are useful labels because the questions for each project differ. Ask the provider to name the exact model, the route it is approved for and its configuration, since the category name is not a full specification. An enclosure, a different entrance or an option can change what a particular proposal includes. Keep those details next to the named equipment in your comparison.

Savaria's Multilift material describes an entrance-style vertical platform route and states that its platform lift does not go through a floor. Its through-floor comparison chart shows how much the indoor models differ: the Luma and Luma L run on a winding drum and are self-supporting, while the hydraulic Telecab and Telecab 17 need a support wall and are listed for up to 23 feet of travel. Other makers have their own figures, but the point holds: entrance access and floor-to-floor travel need separate offers.

Check what the cabin is designed to carry. Savaria lists the standard Luma at 400 lb (180 kg) and describes it for compact mobility aids such as rollators, walkers and canes. For the larger Luma L the chart says a wheelchair is possible and asks buyers to check the dimensions of their chair or device. Ask for the inside size, door opening and capacity of the exact variant, and measure the real chair with the person in it.

For an enclosed home lift, ask what that particular system needs around the cabin. Shaft, support, where the machinery sits, the entrances and related building work all differ by model. A cabin picture shows the finished look but leaves out the structure behind it. Ask the responsible professionals for the planning material and drawings for your house before judging the whole commitment from the interior panels.

Use the category descriptions to start useful conversations. A provider may tell you that one model is not offered for your route, another needs a changed entrance and a third is worth a survey. That is real progress. You do not need a league table of platform, through-floor and enclosed lifts. The aim is to find which specific proposals still make sense for your journey and what each still has to show you.

Map the construction responsibility for each proposed system

Make a building-work table before comparing installed totals. Use rows for site survey, design, floor opening where needed, enclosure or shaft where needed, supporting work, electrical supply, fitting the lift, local approvals or inspection, and finishing. Ask each provider which rows apply to its proposal. Not applicable should be a confirmed answer, never a blank that you read as no work needed.

Put a name beside each task. The lift supplier may do some of the work and expect a builder or electrician to do the rest. Ask: "Who coordinates the trades, and which drawing revision is everyone working from?" Gaps between contracts can appear even when both firms send detailed quotes. You need one understandable project, not two documents that each assume the other firm covers a missing job.

Illustrative upper hallway leading through a doorway to a bedroom.
Editorial illustration

Keep local rules separate from manufacturer examples. Ask local professionals which permissions, standards or inspections apply to the planned work in your home. A US or Canadian code mentioned in a brochure is not the full rule in another country. Your table can hold the question and the person responsible, without guessing at an approval, a permit fee or a legal answer for your building.

Plan how the household will live during the work. Which rooms and routes will be blocked, what must be cleared beforehand, and what happens if a tradesperson finds something unexpected behind a ceiling? A short installation claim usually refers to fitting the lift itself, so ask how many days the whole project, including the builder's work, is expected to take.

Add the handover to the table. Ask who will show you how to use the lift, which documents you will receive and what happens if another trade has not finished. The table can then show why one compact lift still involves a sizeable project at your house, or why another proposal needs simpler preparation. Those are differences about your home, not proof that one whole category is better for everyone.

  • ApplicabilityAsk whether each construction task belongs to this proposal.
  • ResponsibilityIdentify supplier, contractor and project coordination.
  • Local questionRecord who confirms permissions or inspection requirements.
  • CompletionLink finished work, handover and remaining tasks to documents.

Worked example: the porch and bedroom require separate answers

Imagine a family whose father uses a wheelchair. They have two access problems: the front door is above the garden path, and his bedroom is upstairs. They ask for a lift without explaining the two journeys and receive a quote for an entrance platform. That quote may well suit the front door, but it does nothing for the upstairs bedroom, even though the same wheelchair was mentioned in the first phone call.

So the family rewrites the request as Entrance A and Bedroom B. For Entrance A they describe the outside approach, where he arrives and the door he goes through next. For Bedroom B they describe the downstairs room, where he arrives upstairs and how the wheelchair moves through each space. Providers are asked to say exactly which route their lift serves and what other work or equipment the second journey would need.

The entrance quote is checked for the model, the approach, weather exposure and the building work. The indoor quote is checked for the floor, the entrances, the wheelchair itself and the building work. When one provider offers a compact through-floor cabin, they check its listed capacity and inside size against his actual chair, instead of taking the word mobility as proof it will fit.

Next, they decide what is urgent and what they can afford now. An entrance project can be judged on its own merits without buying a larger indoor lift to justify the word future. Equally, if reaching the bedroom is essential, a cheaper entrance lift cannot be presented as the answer to that. The two-route sheet keeps both problems visible and keeps his own preferences at the centre.

Illustrative household discussion comparing two plain folders in a living room.
Editorial illustration

The result might be one confirmed project, two projects in stages, or more assessment before ordering anything. The lesson is simple: separate the journeys before you choose the equipment. Matching each lift to a clearly described trip stops an attractive category from becoming an expensive answer to the wrong problem.

Compare user functions and ownership after route fit is understood

Once a proposal clearly serves the route, look at how the person will actually use it. Ask the supplier to show getting in, the everyday controls, arriving, getting out and how to call for help on the offered model. Platform controls and cabin controls can work quite differently. Write down preferences and doubts, and leave questions about movement or support to the right assessment rather than a points score.

Ask what the manual says about a power cut. Savaria, for example, says the battery-powered Luma keeps working for about 5 up and down trips during a power failure, while its hydraulic Telecab models have a manual lowering mechanism with an optional battery backup. Doors and the alarm need their own answer too. Ask the supplier to show you the page in the manual, and practise the help routine with them at handover.

For ownership, find out who installs and services the lift locally. Ask about routine maintenance, how often visits are due, how to report a fault and what the warranty covers. Parts, labour, call-out travel and the owner's own duties each need a line, tied to where you bought it and the country you live in. Do not count on future repair savings or a resale value unless it is written down.

Think about the effect on the rooms. A lift can change how you move around the house or take over a cupboard, and a decorative finish adds a separate decision. Ask what must stay clear for servicing and for everyday life. Hold off on storage furniture or decorative panels until that is known. A tidy brochure image cannot answer every practical question around the lift.

Finally, keep a short decision note: the route served, the model offered, the work confirmed, the user questions answered and who is responsible for what is left. The next step may be another survey or a changed entrance rather than signing an order. That note will tell you far more than any general ranking of lift types.

  • User sequenceEntry, control, arrival and departure in the offered configuration.
  • BackupModel conditions and the appropriate help explanation.
  • SupportLocal maintenance, fault route and applicable cover.
  • Decision noteRoute served, confirmed scope and remaining tasks.

Questions about platform, through-floor and enclosed home lifts

Is a platform lift the same as a through-floor lift?

No. In the manufacturer examples above, a platform lift serves an entrance-style route without going through a floor, while a through-floor lift travels between two floors through a ceiling opening. The names are useful starting points, but the entrances, permitted travel and building work belong to the specific proposal.

Illustrative loose metal, wood and ivory finish samples beside a blank notebook.
Editorial illustration

Will a compact through-floor lift fit my wheelchair?

Ask for the variant's inside size, door opening, capacity and the devices it is approved for, then have the real chair and approach checked. Savaria's standard Luma is described for compact aids like rollators, walkers and canes, so its size should not be assumed to suit every wheelchair or scooter.

Does an enclosed lift need more building work?

Ask for that model's project requirements and a table showing who does what. Systems differ, and a smaller advertised footprint is not proof of less total work. Keep support, entrances, power and finishing separate. An honest unpriced line is better than a guessed figure added to make one type look cheaper.

Can one installation solve the porch and the upstairs bedroom?

Ask the provider which journeys and stops its lift serves. Treat the entrance and the indoor route as separate briefs until a proposal clearly answers both. The same person and chair do not make the routes the same. A second project may be needed, or the urgent need may deserve its own discussion.

Which approvals are needed?

Ask local professionals about the planned work at your property. Code references from another country should not be copied as your local rule. Write down who confirms the requirements and how they affect the scope. Cutting a floor opening should wait until the right people have confirmed the structure and any permissions.

Does self-supporting or no machine room mean there are no building questions?

Ask which support, controller location, access and site preparation tasks still remain for the actual model. Savaria's own chart lists some through-floor models as self-supporting and others as needing a support wall, which is exactly why the model matters. Ask for the project answer and the responsibility table for your room before anyone installs equipment.

What can I do before buying?

Write down the route, the actual chair or walker and the daily task, and arrange the right survey or assessment. Use the building-work table to spot missing responsibilities. A revised drawing or another professional's answer is real progress. The aim is a proposal that matches the journey, including the option to wait while an essential question is still open.

BEFORE YOU DECIDE

Platform, through-floor or enclosed home lift: buying checklist

These checks organize the decision.

MAKE THE SPEND MEANINGFUL

Platform, through-floor or enclosed home lift: low-cost alternatives

  • Compare a narrower entry-access project when that is the actual problem.
  • Discuss a suitable room arrangement before committing to inter-floor equipment.

In brief

Platform, through-floor or enclosed home lift: questions answered

How does a through-floor lift work?

A through-floor lift is a small cabin that runs on rails fixed in the room below and rises through an opening cut in the ceiling into the room above, usually with two stops. Savaria's Luma, for example, uses a winding drum with a hidden rope system, needs no shaft or pit and moves at 13 ft/min (0.07 m/s). Sensors stop it if it meets an obstruction in either direction.

YOUR NEXT GOOD QUESTION

Make the next step useful.

For installed equipment, take your measurements and questions to a provider. Ask for an itemised local quote; this site does not currently operate a paid quote referral service.

Browse this topicOpen the checklist ↑
How this guide was prepared

AI-assisted editorial research, checked against the linked primary sources.

Written with AI assistance from the sources listed below and checked against them. We have not tested these products in person.

How we use sources and AI assistance ↗

Sources & fact checks

The guide separates sourced facts from editorial questions and examples. How we use sources and AI assistance.

  1. Savaria: Multilift vertical platform configuration ↗
  2. Savaria: Luma through-floor configuration ↗
  3. Savaria: Luma Lift through-floor lift product page ↗
  4. Savaria: through-floor lifts comparison chart ↗
